Posts Tagged ‘ HD-CVI’



Our Goofy Security Camera Videos Part 3: The Final Chapter, Finally

Written By:
Monday, February 23rd, 2015

Finally.. after months of absolutely no demand whatsoever, the third and final chapter… the “Return of the Jedi” if you will… (oh, wait.. that’s not the final chapter anymore).. ok, the “GODFATHER 3″ of our goofy security camera videos trilogy has been compiled. Please withhold your applause til the end.

In the event you’ve been living under a rock, under a tree, on a deserted island… Here’s the premise: For every security camera we produce, we do a video test…. and put those on the inter-tubes for your viewing pleasure. Back in the day, we would occasionally do silly stuff while making these camera demos, primarily to amuse ourselves and hopefully make the videos entertaining AND informative. And while we don’t really do these sillier demo videos anymore, we had some fun making them at the time. Plus, they do in fact show off the video quality of the cameras… so we figured we might as well compile them, so that someday, someone, somewhere in the universe might get a chuckle out of them.

So this is it.. the last of the silly stuff. As usual, we’ve got our 2 trusting guinea pi.. uh, ‘actors’, Ian and Jose.

Heroes
The Talent

…who have always been ready to put their expendable lives in jeopardy… to risk life, limb, and sanity just to demonstrate to the the world the difference between 1 megapixel HD-CVI box cameras and 3 megapixel IP bullet cameras. The responsibility that rests on these heroes’ shoulders would turn most to puddles of liquid Jell-o, but these hearty men soldier on, unafraid of how their immortalized buffoonery will besmirch their family names for generations to come. Anyway, on with the show…

1) Traffic Cone Beat-down
smack

Day / Night IR Demo – CVIOB-EL1MPIR50-D2-E – 720p HD-CVI Indoor/Outdoor IR Bullet Square Economy Cam

Among those of us in the know… traffic cones have a reputation for being jerks.

bad cone
Jerk

Always have. So it was no great surprise to us that when a jerky cone in our warehouse made a flippant remark in Ian’s general direction one day, he went absolutely ballistic and gave it a beat-down to end all cone-related beat-downs.

2) Ian Defies Gravity
balance

Day / Night IR Demo – IPOB-EL3MPIR50-D2 – 3 Megapixel IP Network Square Bullet IR Security Camera

In this video, we see Ian displaying his defining talent… balancing gardening tools.

3) A Dance, A Flappy, and A Roll
dance

Day / Night Demo – 2MP 12X Flush Mount IP Pan Tilt Zoom Security Camera – IPPTZ-EL2MPL12X-Mini-F

Name says it all, folks.

4) Chortle Kombat
fight

Day / Night IR Demo – CVIOD-LX1MPIR100L2812-W – HD-CVI LX Series 1.3MP Varifocal IR Camera

Once every three hundred and fifty-three years (give or take).. a portal to a mystical, magical martial arts tournament opens up in our warehouse, and all manner of deadly ninja demons come to challenge us to random fights in the middle of our tech support sessions. Usually we just ignore them til they get bored and leave, but every once in a while they catch us at a bad time and we have to “take out the trash”. And that’s exactly what happens here.

5) Styrofoam Peanut Allergy
foam peanuts

Much like traffic cones… the bags of Styrofoam packing peanuts in our warehouse can occasionally get a bit of an attitude. Maybe it’s because their soft spongy innards will soon be used to ensure the safe travels of our DVR’s when we send them out into the world. But in this case, we suspect this particular bag had a bone to pick with Ian… a personal vendetta… judging by the sheer ferocity of the attack. The bag just thew itself upon Ian’s weak and helpless body from 20 feet up.

It was at this point that Ian’s savior Heath heard his girlish screams… and came sprinting to the rescue.

heath
Heath, the tragic hero

Using his famed bare-handed hunting skills he typically reserves for bears and mountain lions, Heath bravely wrestled the bag off of Ian’s ravaged person, and then, tragically, despite his valiant selflessness was consumed by the non-biodegradable bag-creature while Ian limped away to bandage his wounded pride.

6) Ninja in Training
ninja

Day / Night IR Demo – IPOD-TP2MPIR50-W – 2 Megapixel TP Series IP IR Vandal Resistant Dome

After his near fatal battle with a sentient bag of Styrofoam packing peanuts, Ian decided it was high time he learn how to defend himself. So after he saved up about 150 bucks, he started regularly attending a ninjitsu school hidden in the back of an abandoned Sizzler restaurant, where he learned his stealthy skills from a ninja sensei cleverly disguised as a hobo. Sadly, after building his confidence though several victorious battles, he later lost his new-found ninja prowess due to amnesia he acquired in a tragic break-dancing mishap.

7) Argument
argue

Day / Night IR Demo – IPOB-EL3MPIR50 – 3 Megapixel IP Network Bullet IR Security Camera

One day, someone took a big bite out of Ian’s p.b.& j. sandwich, then re-wrapped it in foil and put it back in the break room fridge. Ian, understandably took exception to this, as his wife had spend days making that sandwich. He suddenly became suspicious of everyone. He wanted answers, and he wanted them now.. or then, I guess. Ian thought the evidence could be found on the security camera footage, but sadly, someone, possibly the culprit, unplugged the 3 megapixel camera facing the refrigerator. So he took his frustration out on poor Jose.. who simply wanted to spend his lunch break drinking his quadruple-mocha-frappe-whip-latte in peace. The world was never quite the same after this.

8) Cone Drop
Untitled-2

Auto Tracking Demo – IPPTZ-EL2MPIR250L30X-AT – 30X 2 MP Auto Tracker IR IP Network PTZ

Following the infamous P.B.&J. flame out, Jose developed a dark side. He wasn’t taking guff from anyone, least of all from another uppity traffic cone. Look at the pure confidence in which he just casually yet menacingly tosses that cone to one side… like a rapper dropping the mic after besting someone in an acapella rap battle. He just doesn’t give a darn, and he doesn’t care who knows it.

9) Creepy Stare
spooky

Day/Night Demo – CVIVD-LX1MPIR50L2812-W – HD-CVI LX Series 1.3MP Varifocal IR Vandal Dome

Witness the moment Jose’s new-found dark side finally took hold. Spooky, ain’t it? Whatever you do, don’t stare directly into his eyes while saying his name 3 times backwards. Nothing will happen, and you’ll have wasted your time completely.

Well, that’s all, folks. We’ll be back next month with a decidedly less amusing but probably more informative article. Thank you for your patience.

porky2

facebooktwittergoogle_plusredditpinterestlinkedintumblrmail

How to Prevent a Christmas Theft (as Well as All Year Round)

Written By:
Wednesday, December 24th, 2014

685ahFB953367

As you all know Christmas is already here and thieves are on the loose. In this day and age, electronics are what are being gifted and criminals are simply waiting for packages to be delivered to your homes. They are even bolder to go to your door and steal them. Some even break into your home while you are  hard at work and grab all the items under your tree. There is also a black market for electronics that are even set on an Order basis unfortunately. These thieves are more coordinated where they are following delivery trucks and have “look outs” once a package or multiple packages are delivered and steal them to gain a profit. How can you prevent theft at Christmas and all year round?

The video above shows how a criminal hits two houses at the same time, and sadly, even though they have a surveillance system, you cannot make out their faces. There are solutions to these issues.

There is a Startup company that will accept your packages and ship them to you at your convenience. The company is called DoorMan. Their services costs $4 per package or $20 a month. a small price to pay when you are not home. Although this is only at the moment available in California it could become a trend nationwide. There is also Amazon. They allow customers to use lockers in public spaces to pick up packages.

The Importance of Having a High Definition Security System

Below is a video showing the differences between resolutions so that you can understand the necessity of having a High definition system.


**Please make sure that the settings gear is set to 1080P

As you can see with a 1080p camera you can zoom in further and get the facial recognition that you are looking for. The 1080p camera in this video is an HD-CVI camera which is a newer technology that launched this year and is taking over the industry, as it is not as expensive than an IP based System. It delivers the same great High Definition signal as IP.

Integrating Alarm Outputs from Your Security Recorder

You can also integrate our DVR/NVR systems with other devices such as a garage door, which you can have the UPS, Fed EX or USPS guy drop your package inside of your home. You can utilize one of the security recorder’s relay-out to the signal on your garage door opener, which will allow you to open the garage door, monitor what he or she is doing, and closing once he or she has left the garage. You can also have a microphone and a speaker connected to an amplifier and have audio and give commands to the Delivery guy as to what to do.

You can use this diagram here to connect your recorders alarm output here.

The above illustration shows an ELK 912 which is a very popular relay. As you can see you can connect a siren as well if you wish but for our purposes you can see Figure 2 which illustrates how the relay will connect to the Garage Door system.

This works with your Mobile Application as well with TechProSS  (IOS & Android). You can see the channel where the camera in your garage is set, as well as engage the Alarm triggers within the application. Please make sure before making a purchase or getting these items to check to see if your recorder does have the alarm outputs.

Lets move on to the Microphone and Speaker attached to the Amplifier.

As the above video illustrates you will need an amplifier and a horn. There are a few different  amplifiers that you can pick up. Some have even a built-in speaker on them. The video is old but it gives you the idea of how this functions. Let move on to the items that you will need.

  • Mono Amplifier
  • Speaker Horn or normal Speaker if indoors
  • cables and connectors

Connect the Speakers or horn to the amplifier output. Then we need to connect the audio-out to the amplifier. Once this is done we have the Audio Output.

We can now move onto the Microphone side just in case you want to hear the person inside of your garage.

The video below will show a basic installation for a microphone using Plug and Play Cables.

Analog_Microphone_DVR_mini-Y

To read more about connecting a microphone to various DVRs and NVRs click here

Integrating Snapshot Alerts through an FTP Server

We can also further integrate this system to capture and send images base on a momentary switch such as a doorbell. This will send a snapshot to an FTP server.

*This feature can only be set up to transmit the snapshots based on a timed interval.*

This can also be used by adding a PIR that will interface with an alarm input in your recorder. This will allow it to receive the signal and take a snapshot of the person in front of the door or sides if you wish to use this. Many installers will also use PIRs [Passive Infrared Sensor] instead of having the recorder creating a motion from a camera. This allows you to pin point where you want the motion to be captured from, as well as having the ability to set the cameras to 24-hour mode as opposed to motion only.

If you are wondering what application or how to obtain a File Transfer Protocol server, it is as simple as installing software like Filezilla onto your computer.

You will need to open some ports in your computer’s firewall rules. Port 21 is what is used normally and this can be changed to better suit your needs as many other devices might be using this port.

Since we are using this internally we are not required to open the ports on our router.

Open your Windows Firewall and set your rules here. Set an exceptions.

FFM6NZCFIES1X8U.MEDIUM

FQPD611FIES1X9A.MEDIUM

Set your directory. This is where you will have your files stored, and finally  you will need to set it up with users who will be accessing files.

Within filezilla, click Edit->Users

Set your passwords and users along with their permissions.

If you want to go all the way, meaning having the ability to access your FTP server anywhere that you have access to the internet as well as an FTP Client, ensure that you have the manual or gather the information on how to properly open the ports on your router for the FTP server and input your computer’s IP address. Be sure to set your computer to Static IP. I am assuming you have  a Windows computer.

Capture

Navigate to your Control Panel, Network and Internet, Network Connection and select or highlight the correct adapter. In my case my computer is wired so I select the correct adapter and right click hit properties and IPV4. This opens a window where you can designate the IP address for the computer.

If you are unsure if the IP address is being used in your network by another device you can open up a command prompt  [ Windows Key + R] . This will open a window where you can input “cmd” for command prompt and click OK.

command prompt

Once you have the command prompt open you can input “arp -a” this will show all the IP addresses being used on your network.

cmd

This command will come back with all the IP addresses that are live or assigned in your network. It will also show if the IP is Dynamically assigned or statically assigned.

cmd arp

*** You can also used on of my favorite IP scanners. Angry IP Scanner ***

angryip

After reviewing this solution and gathering that you can protect your property as well as any packages coming in or out of your property, you can have the time to enjoy the Holidays without the worries of not having your property not protected.

Happy grinch

facebooktwittergoogle_plusredditpinterestlinkedintumblrmail

Introducing the 4 channel 1080p HD-CVI Mini DVR

Written By:
Friday, October 24th, 2014

4-channel-1080p-hd-cvi-DVR

When you hear the word DVR you automatically think of Digital Video Recorder. Well, what kind of DVR? Cable companies like Xfinity use DVR technology intergraded with cable hardware so you can view hundreds of channels and record up to 4 broadcasts at the same time (of course monthly DVR service fee applies).exfinity The security camera industry uses DVRs to record video and audio data to internal hard drives. It is safe to say that there are IP security cameras that can blow away the traditional analog security camera system, but it really takes a lot of configuration, networking equipment and sometimes big money. Now you have the new HD-CVI systems like the 4 channel 1080p HD-CVI Mini DVR. In this article I will go over the on-board accessories and what you can do with them using the proper configurations with both hardware and software. First I will talk about the inputs:

hd-cvi-2mp-1080p-indoor-outdoor-ir-bullet-camerahd-59881big The 4 channel 1080p HD-CVI Mini DVR has 4 HDCVI video inputs which accept 2 megapixel resolution HDCVI cameras like the CVIOB-EL2MPIR50 that is one of my favorites. These HDCVI cameras are motion detection 100% compatible giving you a great way to not only save hard drive space, but add more days to your recordings. This unit can do wonders when configured correctly; you are able to configure detailed settings in the OSD and at the HDCVI DVR.

Also, the max run on the video feed is a block busting 1600 FEET.

HDCVI-Distance_ip

Motion Detect Example: You can install a 2MP HD-CVI Bullet Camera (CVIOB-EL2MPIR50) at a door entrance that requires a person on the other end needing access through that door. You can not only get that camera feed from the door when the motion is triggered, you can also give the authorized person access from anywhere on site or off site. The configuration is simple all you have to do is have the proper alarm inputs and outputs configured properly both hardware and software.

This unit also can hold (2) 7200 RPM 4TB internal hard drives for ultimate recording.


This 4 channel 1080p HD-CVI Mini DVR also provides 4 audio inputs for real time listening and recording. This feature is perfect if you want to set up 2-way audio communications in a warehouse or at a big company property or just wanting to listen and record audio for future evidence. The connection is simple first you will need powered microphones for the audio inputs and an amplified speaker for the audio output for the listening part, remember all audio can be configured for recording.

The RS-232 is the on board serial port (serial communication transmission of data) for old school configurations. Ordinary COM (Debug), keyboard connection and transparent serial port (COM input and output via network )image4

USB inputs are used by the control mouse to maneuver through the DVR’s menus.

The RS485 port is not needed to use to control our HD-CVI pan tilt zoom cameras like the 720P HD-CVI PTZ with 250 Ft IR. This camera is priceless having the ability to record 1.3 megapixel images while having the ability to zoom in on a perpetrator for real time action. A great benefit of the HD-CVI DVR is that there is no need to run extra wires when wanting to add a CVI PTZ because the transmission is all done through the coax RJ59 cable.hd-cvi-ptz-20x-1_3mp-720p-with-250-59599big

The RJ45 is a 10M/100M/1000M self-adaptable Ethernet port. This connection is what the HDCVI DVR uses to establish the link to the inside and outside world using a router. Without this technology we would not be able to communicate using our PC, MAC or mobile device whether it is an HD-CVI, analog or IP security system.

Alarm inputs is my main focus in this article. Using this feature in the HD-CVI Mini DVR combined with the alarm outputs can create a complete secured location. The alarm relay is 30VDC 2A,125VAC 1A (activation alarm).

Example: You can configure this unit’s alarm capabilities to alert you when sitting at an office environment so when a person walks through a first door or detected by a beam detector it can trigger a sound using a buzzer. This will direct your view to a monitor configured to bring up a camera in that area so you can then use the DVR’s interface or web service to let them in, or you can even use your compatible mobile device to see who is at the front door and give them access.

maglock diagramimage2IMG_6225

This set up would involve an analog door sensor or beam detector, a single 12V relay, a maglock or a normally closed door strike, 12V power supply, high grade alarm wire and a 4 channel 1080p HD-CVI Mini DVR. The configuration is simple: First you wire and configure the power supply to the relay and then you wire and configure the DVR alarm inputs and outputs to the (output) MAGLOCK and the (input) to the sensor. The next step is to set up in the GUI ( Graphic User Interface ) at the HDCVI DVR.

First, if using the unit’s interface you can click on the setup tab and then click on the event tab and go to the alarm page. There you will configure the alarms inputs and outputs. You start out by enabling the channels and setting the type, antidither, record channel, delay, alarm out, latch and tour remember to hit save after the configuration.

alarm1

Outputs:

USB outputs that uses thumb drives for backing up settings and events.

backup

Alarm outputs, like I mentioned previously in this article, give you ultimate access controls right at your finger tips. Imagine if you had control over door security when a burglary or an in-house crisis arises. You can really try to control the situation if you can restrict access to doors leading to potential victim’s right from your PC or a mobile device.

event

Video BNC output can be configured using the spot out matrix control. You can display desired video windows and tours with out seeing the configuration menus. The HDMI and VGA outputs will display the HDCVI’s full menu functions but you can still configure these monitors to display a tour.

image3Tour

The audio output is used to configure a speaker for listening purposes.

In conclusion the 4 channel 1080p HD-CVI Mini DVR can be used for many many configurations. It is a cost effective unit and at the same time performing at optimal peaks using the inputs and outputs of this new technology would put you ahead of the game.

You can read more about this HD-CVI DVR in the manual here.

facebooktwittergoogle_plusredditpinterestlinkedintumblrmail

Invention of the Security Camera and Recording System

Written By:
Monday, September 22nd, 2014

IMG_5991

Everyone dreams about some kind of invention that they know will make a difference in the world. Back in 1933 a chicken keeper accomplished that. At first his invention was not taken serious but now we see him as the first amateur photographer that invented the security camera. His name was Mr. Norbury, from London England, and he had set up a security camera system using a small box camera wired through iron pipes and booby-trapped a door where he kept his chickens. When someone tried stealing his eggs he would trip a lever balanced by sand bags to pull the trigger, taking a snap shot picture of the thief. Mr. Norbury was successful in catching his plumber and using the picture as evidence. When the judge asked Mr. Norbury who took the picture, he said, “well your honor, the thief did.”

traffic

Security cameras have come a VERY long way since then and now we use them in our everyday lives from the government to the regular mother and father wanting to keep an eye on their house keeper or nanny. You can find cameras practically on every corner from traffic lights to schools and I personal love the aspect that my children can have some piece of mind when attending school. The operation, design, shape and color vary for these image capturing boxes. You can install dome, bullet, vandal proof and pan-tilt-zoom camera that have great features like auto tracking.

One of my favorite new security cameras is the Panoramic security camera it gives you a full human perspective when viewing the live video stream, the experience is like actually being there in person. This new type of technology uses multiple cameras, usually 4 high-resolution cameras side by side in one housing apparatus using all the cameras video inputs and converting them into one panoramic stream. Then the camera encodes and delivers to any viewing device providing a 200 degree view. This is great when wanting to capture a large area using only 1 camera install installation. These cameras have the capability to be viewed from anywhere in the world and on most mobile devices using the manufacture’s app.

imagesCAGOU7R0

IMG_5974

Another one of my new favorites is the IPPTZ auto tracker. This security camera can pan left, right, up, down, zoom and focus at the control of the user. The feature that I love is the auto tracker, as it has the ability to track and follow a target when detected. When connected to the web service utility you can configure settings like zones, tripwire and alarms so when an object crosses the configured zone, alarms can go off and it will auto track that object until it’s out of view. Officials all around the world use this technology along with face recognition to track and capture known fugitives.

pan-tilt-security-cameras-30x-2-megapixel-auto-tracker-59892big

Click on picture above for more info

What about the recorder?

vcr

VHS (Video Home System) format for the VCR (Video Cassette Recorder) that a Japanese company invented in the 1970’s. JVC was in financial ruin but Takano and Shiraishi continued to work on the project in secrecy within the video division. By 1973, the two engineers successfully produced a functional prototype

vfs

In the past there was no way to record live CCTV footage, but then came the VCR  allowing multiple events to be recorded to an analog VHS tape. Time and space was very limited to these recording devices.

IMG_5994

Now we have DVRs and NVRs (Digital Video and Network Video Recorders) capturing and writing video data to hard drives, increasing the time and space you can save. Now companies are inventing new integrated units like the hybrid and tribrid combining analog, IP, and CVI Technology.

DVRClick on image for more details

Imagine, when you’re building your own custom computer or gaming system you start with the case, well it would be awesome if there was a company that sold custom-built DVR/NVR cases, motherboards, memory, hard drives, power supplies, BIG fans and all the cool accessories that can be added to give style and personality to these units. One of my pet peeves when building a custom computer is to always have proper cooling and ventilation, fast hard drives, powerful power supplies, video card, cables and so on… You never know what the future holds!!!

IMG_5989

IMG_5990

Cabling, cables and connectors have also come a long way. Transmission of data/signals over cable started with AT&T using copper wire strung along telephone poles. Telephone signals traveled down these lines as analog electrical waves to form voices and each call required 2 wires to form a complete circuit.

linesman phone

Broadband began when the demand for more television broadcast signals skyrocketed and now the coaxial is born being the first broadband medium. AT&T installed its first coaxial cable between New York and Philadelphia on 1936. One of the first security camera systems used coaxial for the transmission of video data to a monitor. Here at Security Camera King we have RG59 Siamese cable with high-grade copper shielding for high-speed transmission. Attached to the cable is a pair of power wires making installs a breeze with maximum video signal run length is about 750 feet. Microwave radio relay is coaxial and microwave radio relay working in tandem. It is a broadband system by which telephone and television travel via radio along a series of towers.

old tvimagesCAX8JSHT

Fiber optics systems, The New Cable on the block is a technology that uses rapid pulses of light traveling on fibers made of ultra pure glass. This digital medium is one of the best and fastest way of transmission by far, able to send data over miles of cabling with ultimately no interference.

-i386_photobucket_com-albums-oo303-llisallindsay-ANIMATIONS-gif08llisallindsayimagesCA2Z1EUYimagesCA4IFYOK

Cat5/6 cabling has been around for a bit, connecting networks and computers together for businesses and residences. Now security camera systems can be configured using IP camera technology.

rg59

This type of configuration is ideal when wanting to have high-resolution megapixel quality to really catch the identity of a perpetrator. Category 5 and 6 cable max run is around 300 feet. When the network configuration is configured correctly these systems perform flawlessly. The ability to log into each camera’s interface and make detailed adjustments is priceless.

POE is another new feature I love about the Ethernet hookup. The Installer’s Dream, Power over Ethernet- one cable carrying both data and power to the IP cameras, no need to power the camera locally.

poe

While on the subject of new technology try checking out HD-CVI, this configuration uses RG59 coaxial cables to transmit HD quality high-resolution feed to the HD-CVI DVR, recording awesome events to your hard drive for better recognition. The great thing about HD-CVI is that the max run length of the Video cable is 1600 feet, WOW!

HD-CVI-IconHDCVI-Distance_ip

For more info on HD-CVI click on the picture above

In conclusion the evolution of security camera systems has come a long way; I sleep very comfortable knowing that my Security Camera King System is keeping an eye on my family, business and home.

facebooktwittergoogle_plusredditpinterestlinkedintumblrmail

Introducing The Tribrid DVR (HD-CVI, IP, and CCTV all in one unit!)

Written By:
Friday, August 29th, 2014

Tribrid DVR - HDCVI IP and CCTV in one unit

This is the supreme standalone upgrade solution. If you’re looking to keep up with new SecurityCameraKing.com technology then this Tribrid DVR is your answer. If you have installed previous analog systems and you have great cameras and beautiful cables and power supplies in place and you have upgraded all of your hard drives, replaced network routers and switches but you still have your old school analog DVR that is ready to retire. Well guess what? You can keep your good analog cameras, power supplies, hard drives and network hardware. All you need is the new Tribrid DVR using analog, HDCVI, and IP camera technology. You can now show off your new Tribrid to your friends, family and business associates by incorporating new HDCVI technology and IP megapixel cameras. If you’re looking to add more cameras or just want to replace exciting cameras with higher resolution units then the Tribrid will do the job. Setting up the unit is a breeze, I will illustrate some simple setups, new functions and configuration for the new TRIDVR-EL16.

Connecting HDCVI, Analog and IP cameras to the Tribrid

Connecting cameras to the TRIDVR-EL16 can get tricky but SecurityCameraKing.com has 5 star tech support that will help you the whole way (for free), but if you’re one of those do it yourselfers, then here are some simple to follow set up instructions. First, logging in to the system is the same as all of our DVR, NVR, and Hybrid systems. The default user name is admin and the password is admin. After logging in you will encounter the wizard you can just exit out of. From the main menu go to Camera.

Tribrid DVR Menu1

In the image page you will see the channel selection (Drop down box). You can configure each COMPATIBLE cameras saturation, brightness, contrast and sharpness, just remember to save after every modification.

Next is the Encode page were you configure your Compression, Resolution, Frame Rate, Bit Rate, Audio and sub stream per COMPATIBLE camera.

Tribrid DVR Menu2

Next in line is the Cam Name. Here is where you name your camera channels. It is a brilliant idea adding a name to a channel/camera, you automatically know who, when and where the even occurred. Example front door, back door, bedroom or backyard on February 3 2014 at 7:30pm.

Tribrid DVR Menu 3

Now the very important part, the Channel Type page. Here is where it can get a little tricky. The Tribrid’s BNC inputs are defaulted using HDCVI cameras. The adjustment is simple just switch the channel you have the analog camera connected and enable the analog field.

Tribrid DVR Menu4

Tribrid DVR Menu5

When connecting and configuring an IP camera you have to start from the last channel of the Tribrid. For example if you have a 16 channel Tribrid DVR then you would start adding cameras from channel 16 and down, so the first IP camera you connect and configure will be channel 16. You would copy the same configuration as the HDCVI described previously and still be in the channel type page and then towards the bottom of the page there is an arrow selecting next page. Go to page 2 and select IP on channel 16 for your first IP camera, 15 would be the 2nd IP camera and so on. Remember if you have any question or concerns you can always contact TechPro Security Support Monday through Friday from 9am to 6pm Eastern Sunny Florida time.

Tribrid DVR Hardware.

The motherboard is strong and smart and you can install up to eight 7200 RPM SV-35 3TB Hard Drives capturing proper resolution and long length recording with no hassle. On the back of the unit you have HDMI, BNC, VGA, Audio, RJ-45, Alarm, PTZ control, USB and e-sata inputs as well as other outputs.

Tribrid DVR Inside Hardware



DVR Tribrid System Connection

Tribrid DVR Remote view configuration.

Network configuration is the same as all of our Security Camera King recording units. TCP/IP must match your network, the TCP port should be defaulted at 37777 and the HTTP port should be changed to 88 (the TCP and HTTP ports has to be forwarded in the router to have external access).

Tribrid DVR Menu6



Tribrid DVR Menu7

Email alerts can be configured here under the same network sub-menu, utilizing motion or alarm detection to send push emails to your mobile device alerting you who or what has infiltrated your space.

Tribrid DVR Menu8

Tribrid DVR Motion detect recording or 24/7 recording.

The setup is the same as all of our other recording units, go to storage and configure the Schedule, HDD Management, advance and record as you would like normal. If you need more assistant on the setup please feel free to contact a SecurityCameraKing.com Technician.

Tribrid DVR Menu9

Tribrid DVR Menu10

Tribrid DVR Menu11

Tribrid DVR Menu12

Coming soon – New P2P 2D bar code App scanner

When trying to connect to your security camera system it is difficult and it involves configuring sophisticated network settings so you can view your family and business via your Phone, Tablet or any computer in the world that has Internet access. This new and upcoming feature will make life much easy when configuring remote external access. REMEMBER Coming Soon!

Tribrid DVR Menu13

Tribrid DVR System Settings

The general page is where you need to configure your Device ID and number, language, Video Standard, HDD Full option, Pack duration, Real Time Play, Auto logout and mouse speed. You want to make sure you adjust your date and time to your timezone because if you need time and date stamp file for evidence it needs to be correct.

Tribrid DVR Menu14

The PTZ page is very important when installing an analog, CVI or IP PTZ, the configuration just needs to match the PTZ camera.

Tribrid DVR Menu15

The account page is where you give privileges to users. Assigning accounts are easy with the new interface, make sure not to delete your technician’s administrative password because when you need support, the fastest way in to fix the issue is logging in as an administrator (so don’t forget the admin password).

Tribrid DVR Menu15

In conclusion in my experience, this unit blows away any other upgrade. WHY? Because you get the best of three worlds. You can upgrade your whole system and have indoor/outdoor HDCVI cameras and Smart Auto Tracker IP cameras in your warehouse or retail store while still keeping your existing analog cameras you don’t want to discard. One small step for analog, a giant leap for HDCVI and IP technology.

Here is a short unboxing video of the Tribrid DVR (TRIDVR-EL16)
