Posts Tagged ‘ license plate capture’



License Plate Capture

Written By:
Friday, May 23rd, 2014
License Plate Security Cameras

Cameras properly positioned to capture license plate information can be extremely beneficial in almost any location. However, they require proper setup, positioning, and should be placed appropriately. In this article we will discuss the best practices for installing and setting up a license plate camera as well as the many benefits of having one in place.]

License plate capture can be useful for tracking and identifying the movements of a vehicle, both in and out of a secured area. This can be useful if an accident occurs or if criminal activity is reported where only a vehicle description is available. There have been numerous occurrences where the only identifiable information provided by witnesses was a vehicle description. If that vehicle description can be tracked back and matched to a license plate camera then positive identification of the owner can usually be obtained.

There have also been instances of drivers ramming guard rails and/or security gates to gain access without properly providing credentials. This can be very costly and the cost of repairing damages could fall on the property owner if the driver cannot be identified. This type of activity is criminal in most locations as it can endanger anyone near the gate at the time of the event as well as allowing unauthorized persons to drive into the facility without being stopped for verification of identity.

One of the most important aspects in positioning the camera involves stopping the vehicle in a spot where the camera can observe the license plate. There are some very expensive cameras that can capture the plate of a fast moving vehicle. However, to maintain a reasonable budget and to ensure that the plate is captured properly it is best to bring the vehicle to a complete stop in a predetermined location in clear view of the camera. This can be achieved simply by putting in a “Stop” sign. However, the effectiveness of a “Stop” sign may not always provide a guaranteed stop. Placing a gate or guardhouse may prove more effective in bringing vehicles to a complete stop and ensuring a higher quality capture of the license plate image.

There are other factors to consider, such as the location of the camera in relation to the sun. Facing a camera due east to try and pick up license plates may cause it to be blinded during the morning. Conversely, aiming it due west may cause it to be blinded in the afternoon. To avoid extensive exposure to the sun which could affect the image and potentially damage the sensor in the camera you should consider a shaded area for the stopping of vehicles to capture plates.

You should also consider the approximate location of the license plate on vehicles. Different states have different regulations in regards to this. For example in New Jersey you are required to have a license plate on the front and the back of the vehicle. While in Florida you are only required to have a license plate on the back of the vehicle. You should not only consider what is normal for your region, but also what out of state visitors may have on their vehicles.

License plate cameras should use a variable focus lens to tighten the shot on where plates are. This may take some adjustment using a vehicle to get the focus just right. You want a shot that is zoomed in enough to read the plate, but still wide enough to catch license plates that may be positioned differently. For example, some vehicles are higher than others, especially commercial trucks and cargo vans. While other vehicles, such as low riders may have their license plate very low and close to the ground. This could cause you to not get the license plate in the shot if the camera is zoomed in too closely.

It is also recommended that you use one license plate capture camera per lane of traffic. If you have multiple lanes of traffic leading into or out of your facility, using just one license plate capture camera could cause the view to be obstructed by vehicles that are in the lane closest to the camera. This would cause you to have a nice shot of the side of a vehicle rather than the intended license plate.

You should also consider what will happen after hours when planning for a license plate camera. For example, you may wish to use a license plate capture camera that has strong infrared capabilities or has forward facing illumination. You may also plan to have the cars stopped in a well-lit area that is maintained and or monitored for lighting issues. Having a vehicle stopped in front of a license plate capture camera that does not have infrared and is in a dark or dimly lit area may not produce any image at all or possibly an obscure image of a vehicles tail lights with no clear visibility of the license plate.

Another good practice is to ensure that your license plate capture camera is either recorded on the same DVR or NVR as the rest of the cameras in your facility or if it’s on a separate unit, ensure the times are properly synchronized across all of the cameras. This will avoid many difficulties in matching a vehicle to a specific event. If the time is off by hours or even days, it can be a very daunting task to isolate and identify a specific license plate and the vehicle it belongs to.

In conclusion, simply placing a camera at an entrance and expecting it to provide high quality identifiable pictures of license plates is not enough. Care should be taken in planning where the vehicle will be stopped at, where the license plate capture camera will be, what lighting is in the general area, and where the camera should be pointed. Using a vehicle during the alignment process can greatly increase the results as well. Adjustments can be made after installation, but having it in the appropriate location is key.

facebooktwittergoogle_plusredditpinterestlinkedintumblrmail

How to Capture License Plates with Security Cameras

Written By:
Tuesday, November 12th, 2013
Capturing License Plates With CCTV Surveillance Cameras

Using a surveillance camera to capture video footage of the license plates of vehicles that are entering and leaving an area has proven to be an effective way to have a record of the traffic at the location. Law enforcement agencies across this country are making use of this technique more and more commonly. It has already helped them to gather information that has helped them follow vehicles thought to be driven by individuals that were suspected of crimes, even when the officer is nowhere near the vehicle. The data that these cameras provide can be invaluable if a crime takes place, allowing someone to review footage and know who was in the area with certainty. The data collected about these license plates can be more helpful to law enforcement officials when trying to identify a suspect then the highest quality images of a suspect’s face. The installation of security cameras for this function may seem deceptively simple but if it isn’t done correctly you will not get the video that you need. This article will provide with the information that will you to accurately record video footage of license plates every time.

The first consideration that you should look at for licenses plate capture is the location. Finding the right place to record useful video of these small fast moving targets is a key element in the process. The place where you set up for this should be a place where traffic is already controlled in such a way to be beneficial for this process. Someplace where traffic is already forced to stop, such as a stop sign or the gate of a community, is an ideal spot. The entry way of a gated community is probably the best location because it will also be a place where there are fewer lanes of traffic and you will need a dedicated license plate capture camera for every lane of traffic that you’re monitoring, so fewer lanes will require fewer cameras to get the video footage that you want.

The next thing that you should consider for this process is making sure that you have the proper equipment to record the best possible video of the license plates. There are many different security cameras on the market today that offer high quality video, but few are actually designed to record high quality video of a license plate. The cameras that perform this function correctly have to be able to deal with the glare of light bouncing off the reflective surface of the plate, angles that are often challenging, widely varying illumination levels, being able to record video of a moving target that isn’t blurry and they usually have to cope with moderate to long distances. All of these factors, in addition to other location specific issues that haven’t been mentioned, that the camera must deal with are the reasons that you really need to have a surveillance camera that is specifically designed to capture video of license plate despite the difficulties.

Another part of this process that you must account for, in order to do it correctly, is properly monitoring the area where you will be identifying the license plates as well as providing an exterior view of the vehicle. A camera that can capture video of the car or truck and its activity will provide you with some very useful information particularly when you can identify the vehicle’s license plate at the same time. Making sure that you at least have a reasonable high resolution camera for this overview purpose is a very good idea, but it doesn’t need to provide the same type of high quality of video that the license plate camera should. A moderately high quality camera for the overview role will allow you to have a high level of detail in the video shot to help you get an accurate understanding of what type of vehicle the license plate is attached to and how many passengers are in it. This over view camera can also provide other details about the vehicle such as the relative speed that it’s traveling and whether it’s being driven recklessly or not. It’s also a good idea to get a camera for this purpose that has a varifocal lens so that you can adjust it to the camera view that’s needed from the position that’s available for mounting the camera. This type of lens will let you compensate for a reasonable amount of distance from the targeted area and make sure that it’s focused on the exact point that you want.

So now we have established that an overview camera needs to be mounted in such a way that it can view the traffic choke point where you are going to be capturing video of license plates. The next step is to make sure that you have the surveillance camera that will actually be doing the license plate capturing in the right place. The traffic point that you choose for this installation should allow you to know where the target vehicle will stop. The license plate capture will need to be positioned in such a way that it’s field of vision will be focused and the lens will need to be zoomed in to the point that the license plate will take up about sixty percent of the camera’s view. Make sure that you take into account the varying heights of the different types of vehicles that will be traveling through the area. You will need to have one dedicated license plate capturing camera set up this way for each lane of traffic that you wish to monitor.

Once you have these cameras set up in the manner that’s described in this article, you should be ready for monitoring the traffic in the area in great detail. It’s a good idea to test how the camera views will catch the license plates where the vehicles will be stopped and the make the fine tuning adjustments in order to guarantee that you will be getting the video that you desire.

facebooktwittergoogle_plusredditpinterestlinkedintumblrmail

CCTV Spy Cameras

Written By:
Monday, June 18th, 2012

license plate capture cameraOne of the most important things you need to have in place around your home is a security system. They work to help protect valuables around the globe on a regular basis. There is a huge risk when you think about not having all of your valuables under surveillance. Can you imagine how much money you would have to spend out of pocket trying to replace everything? It is imperative that you address the situation beforehand and eliminate having to deal with the unforeseen consequences later on down the road.

Closed circuit television systems are a fabulous way to be able to monitor the safety and security of your property from just about anywhere, without having to worry about any human intervention. They are one of the most powerful forms of technology on the market, not to mention their sophistication is far beyond what a lot of people might expect. Security cameras are used in government and commercial businesses everywhere, such as in an airport, military establishment, shopping malls and business of all sizes. In reality, anyone that has valuables that need protection can find a benefit in utilizing a security system around their property.

Given all of the sophisticated features of the surveillance systems, you will be able to have motion detection enabled to help save on your recording and storage space. Another great feature is the facial and license plate recognition, which will make sure the intruder is caught on tape every time. Motion detectors will catch things as simple as someone throwing an item out of an apartment complex that might cause harm to someone walking along the streets, which in some areas is a huge problem for pedestrians. No one wants to be walking along as some crazy object comes barreling down on them from above. Can you imagine how much damage that could do?

Facial recognition cameras are more commonly used at sporting events, subways and other locations where there is a lot of traffic in and out of the area. Number recognition systems help to recognize the opening of a security gate, which can help alert the officials to anyone who is unwanted and unlicensed and make sure they are apprehended in no time.

In a casino, the closed circuit television systems are used for monitoring all of the activities that are occurring at the gaming tables around the clock. Some of the systems on the market are able to detect even the slightest movement of the hand and point out any croupiers in an instant. How much better could it possibly get than that when it comes to your business?

With all of the advancements in the storage and replay technology, the cost has been substantially reduced to help allow more footage to be recorded for an extended period of time. You can instantly replay everything that has been recorded, such as a sporting event on your home theater system.

Considering all of the advancements in closed circuit television systems over the years, there are more and more compact systems on the market to offer you the recording features you need at a price you can afford. Before you know it you will be able to have a full security system in place and have everything protected for years to come. Security footage can be viewed over the Internet, which allows you to have an alert sent to your phone along with the live footage. You will never be without the ability to access your security footage, as long as there is a computer and the Internet nearby. Take the time and check into all of the amazing options there are for you to choose from when it comes to protecting your home and your business. No one should have to worry about their safety again and now you won’t have to.

Do not heitate to contact us for more information.
