16 Channel Elite 4K Security NVR with 16PoE (8 ePoE)

(1 customer review)


Out of stock


Join the waitlist to be emailed when this product becomes available

SKU: NVR-EL16M-16EP Categories: ,

Recommended Accessories

18x18x5 Small Steel Lockbox with fan designed for 1U DVRs & NVRs
18x18x5 Small Steel Lockbox with fan designed for 1U DVRs & NVRs
21x24x8 Large Steel Lockbox with fan designed for 1.5 and 2U DVRs & NVRs
21x24x8 Large Steel Lockbox with fan designed for 1.5 and 2U DVRs & NVRs


Number of Cameras
Number Of HDD
Max Recorder Resolution

This is a 16 channel Elite series NVR with 16 ports of standard PoE and 8 of those supporting ePoE and capable of supplying data and power up to 800m or almost half a mile. We love the versatility of this NVR and how perfect it is for so many different security scenarios. When it comes to HD recording, this NVR is capable of recording resolutions as high as 12MP and still as low as 1MP for those of you that aren’t ready to go full 4K already! There’s a maximum 320Mbps incoming bandwidth but with a Quad Core Processor and the embedded Linux OS, this standalone security recorder will be capable of handling the large amount of data generated by up to 16 Ultra HD cameras. Thanks to the compatibility with the ONVIF 2.4 protocol, this NVR will be able to work with numerous 3rd party IP Network cameras.

You’ll be able to view your video live and during playback using either an HDMI or VGA connection and you’ll be able to view up to 4 channels at 8MP resolution on HDMI. Imagine being able to see details 4x your average 2MP/1080p camera! Digitally zoom recorded video to see tattoos, facial details, monetary transactions, playing cards, license plates, etc. It’s much easier to identify a criminal and prove wrongdoing if you can actually see something that can be used as a positive identifier. Besides, now you can really put that 4K television to use!

There are a number of features put this NVR at the top of its class. ANR or Automatic Network Replenishment will trigger storage of video data to an IP camera’s SD card when there is a network loss and the NVR will automatically download the video once the network connection is renewed. The NVR has IVS or Intelligent Video System capabilities that allow for triggers based on a wide range of Smart features including Tripwire, Intrusion Detection, Missing and Abandoned Object Detection, Face Detection and even People Counting capabilities.

Using the latest H.265+ video compression codec, video data will be processed more efficiently with a reduction in bit rate and storage requirements that are up to 70% less than the previous H.265 standard. With room for 2 hard drives up to 8TB each, you’ll have plenty of space to save your footage and you can also plug a removable flash drive into the USB port for temporary or additional storage. When you use the dropdown tab up above to add hard drives to your purchase, we will install, configure, and test them before we send your NVR to you!

This product comes with a 3 year warranty! FREE US based tech support for the life of the product! Don't forget to download our FREE remote viewing applications, available on IOS & Android! For further warranty information, click here.

Enhanced POE

ePoE you can simplify the wiring requirements enabling you to reach distances of a single run up to 800 meters (over 2,600 feet) at a speed of 10Mbps.



ePoE, or enhanced Power over Ethernet, is an innovative solution that utilizes specialized algorithms capable of extending how far both IP and analog security cameras can reach. ePoE devices are now standard on ONVIF devices and can even be incorporated into traditional PoE systems. What makes ePoE devices different is that they have the capability of converting coaxial infrastructures with the latest IP devices. This capability makes it possible to increase transmission distances through both coaxial and ethernet cables.

4K Ultra High Definition Resolution

4K resolution is a resolution that consists of 4,000 pixels. 4K, which is specifically 3840 × 2160 (4K UHD), has now become the standard for video quality. 4K resolution is not just for TV graphics. It’s now being utilized for modern video surveillance systems and can be an important aspect for high-quality security cameras in order to provide a better quality recording, deliver better results for analysis, and ultimately make it clearer to see for everything from security to entertainment.

Remote Viewing Apps

The ability to view security camera systems remotely has transformed the video surveillance industry in powerful ways. Prior to this innovation, manned users were needed on location to view live feeds. Now, it’s possible to view live camera feeds digitally through network-connected devices. IP security cameras make this innovation possible. With remote viewing, anyone, from anywhere in the world, can visibly watch live camera feeds.

Number Of Cameras 16
Number Of SATA Connections 2
Has Alarm Inputs / Outputs Yes
Video Output Types HDMI / VGA
Video Output Resolutions: 3840×2160 , 1920×1080 , 1280×1024, 1280×720 , 1024×768
Size 1U
Resolutions Capable 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1.3MP, 720P, D1
Max Bandwidth 320Mbps
Display Screen Split 1/4/8/9/16
Compression of Video H.265+
Connection Apps Smart PSS, iDMSS, gDMSS
Document Downloads
Product Specifications Detailed Feature List and Product Specifications
Product Manual Original Product Manuals
