Description
Description
Presenting the NVR-SB32C-P4K from our Sibell series. This NDAA-approved NVR is able to handle up to 32 cameras up to 12 Megapixels @20 FPS or cameras up to 8 Megapixels or 4K @30FPS.
Using H.265 encoding for increased efficiency when compressing data, to increase the maximum amount of footage recorded as well as getting a higher quality image from a lower bit rate and with a capacity of 4 drives up to 10 Terabytes each, you have the ability to store a large amount of footage.
The NVR-S32P4P8 also comes with a Built-In 16 port POE switch for plug & play with Sibell IP cameras as well as Two 1000Mbps Lan ports, meaning you could have all 32 channels isolated from your network, keeping the traffic generated by the cameras off your network.
This system has a Bandwidth of 192Mbps incoming & outgoing, along with two HDMI ports & a single VGA port. The NVR-S32P4P8 is also capable of playing back up to 4 channels at the same time, allowing you to review multiple cameras’ worth of footage at once. This can be done with a monitor connected to the HDMI port that outputs up to 4K or via the VGA.
VCA or Video Content Analysis features like tripwire, region intrusion, and missing or abandoned objects are supported by the NVR-SB32C-P4K. Alerts can be set up for when these rules are broken once the system has been connected to your Sibell mobile phone application.
Like all of our Sibell NVRs the NVR-SB32C-P4K can be remotely monitored from anywhere on your Smartphone using the free Sibell Mobile application on both IOS and Android or the NVMS PC program which is available on our site for free.
This product comes with a 3-year warranty! FREE US-based tech support for the life of the product! Don't forget to download our FREE remote viewing applications, available on IOS & Android! For further warranty information, click here.
Features
NDAA Compliant
Our line of NDAA-compliant products is our newest series, designed to meet the requirements outlined by the National Defense Authorization Act (NDAA). The NDAA imposes restrictions on the utilization, procurement, or sale of specific components or brands of equipment for federal agencies. We ensure that our series of NDAA-compliant products fully adhere to these regulations.
This series encompasses a diverse range of advanced technologies and analytics, offering a comprehensive lineup of products to cater to your needs. Whether you are purchasing a new system or expanding your existing setup, we highly recommend considering our NDAA-compliant product series. It not only aligns with the latest federal requirements but also represents the future of our security camera lineup. Additionally, our NDAA-compliant product series is competitively priced, comparable to our other product lines, and often offers even more cost-effective options.
POE
PoE, or Power-over-Ethernet makes it possible to install security cameras and video surveillance equipment without traditional AC power. It permits devices to have electrical power to more places without having to install an additional electrical infrastructure or outlet at every point they are placed. The main benefit is that surveillance devices can be installed without needing a professional electrician, saving people money and simplifying the process, making security cameras more cost-effective.
4K Ultra High Definition Resolution
4K resolution is a resolution that consists of 4,000 pixels. 4K, which is specifically 3840 × 2160 (4K UHD), has now become the standard for video quality. 4K resolution is not just for TV graphics. It’s now being utilized for modern video surveillance systems and can be an important aspect for high-quality security cameras in order to provide a better quality recording, deliver better results for analysis, and ultimately make it clearer to see for everything from security to entertainment.
Remote Viewing Apps
The ability to view security camera systems remotely has transformed the video surveillance industry in powerful ways. Prior to this innovation, manned users were needed on location to view live feeds. Now, it’s possible to view live camera feeds digitally through network-connected devices. IP security cameras make this innovation possible. With remote viewing, anyone, from anywhere in the world, can visibly watch live camera feeds.
| Number Of Cameras | 32 |
| Number Of SATA Connections | 4 |
| Has Alarm Inputs / Outputs | Yes |
| Video Output Types | HDMI/VGA |
| Video Output Resolutions: | 4K × 2K / 1920 × 1080 / 1280 × 1024 |
| Size | 1.5U |
| Resolutions Capable | 12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/ 720P/960H/D1/CIF |
| Max Bandwidth | 192 Mbps |
| Display Screen Split | 1/4/6/8/9/13/16/25/32/36 |
| Compression of Video | H.265S/H.265+/H.265/H.264 |
| Connection Apps | NVMS Lite, Sibell Mobile , Super Live Plus |
| Perimeter Protection | No |
| Object Detection | Yes |
| Face Detection | Yes |
| Face Recognition | No |
| Smart Motion Detection | No |
| LPR | Yes |
Video
Downloads
Document Downloads
 | Product Specifications | Detailed Feature List and Product Specifications |
 | Product Manual | Original Product Manuals |
