5 inch LCD IP-TVI-CVI-AHD-CVBS Camera & Cable Tester

(1 customer review)


Out of stock


Join the waitlist to be emailed when this product becomes available

SKU: TOOL-TP-HD5IN Category:



Works with IP, HD-CVI, HD-TVI, Analog, and AHD.

This 5 inch IPS touch screen IP camera tester is designed for the installation and maintenance of  HD coaxial cameras, IP cameras, Analog cameras, and other security equipment. This unit supports many ONVIF PTZ and analog PTZ control as well as cable test functions. The screen’s 1920 x 1080 resolution enables it to display HD cameras and analog cameras in high resolution. CCTV installers often need to carry a variety of testing tools to complete their work. Using the all-in-one camera tester, working conditions are made safer and increases productivity.

●5 inch IPS touch screen, 1920 x 1080 resolutions
●8MP CVI/ TVI/ AHD camera test
●8MP EX-SDI, HD-SDI, 3G-SDI test*
●H.265/H.264, 4K video display via mainstream
●HDMI Input, support 4K 30FPS*
●VGA input, support 1920 x 1200P 60FPS*
●DC12V 3A, max 25.5V (PoE+) 48V PoE power output
●RJ45 TDR cable test, cable quality test
●Auto HD, auto recognize HD coax camera type and resolution
●Rapid ONVIF, Create the test report and modify IP address, etc
●UTP cable test, detect the near-end, mid-end, and far-end fault point of the network cable crystal head


4K Ultra High Definition Resolution

4K resolution is a resolution that consists of 4,000 pixels. 4K, which is specifically 3840 × 2160 (4K UHD), has now become the standard for video quality. 4K resolution is not just for TV graphics. It’s now being utilized for modern video surveillance systems and can be an important aspect for high-quality security cameras in order to provide a better quality recording, deliver better results for analysis, and ultimately make it clearer to see for everything from security to entertainment.
