5MP 2.8mm AI Starlight IR Vandal Dome W/ Alarm and Audio

$169.95

SD CARD

SD Storage Options

Compatible Mounts

SKU: WM-EL203W-PM-EL152-E
Wall Mount Pole Mount Combo for EL Series Dome Cameras
$46.24
New Wall Mount for EL Series dome cameras
SKU: WM-EL203W
Wall Mount for ELITE Series dome cameras
$19.29
Junction Box Mount
SKU: JB-EL137
Junction Box Mount
$29.95
Description

Description

5
Megapixel

2592 × 1944
Resolution

2.8mm
Fixed Lens

164 FT
Starlight / Night Vision

Description

The IPVD-ELS5IR28A-AI-EP is a 5 Megapixel (2592 × 1944) camera from our Elite series of surveillance equipment. It’s Artificial Intelligence (AI) tries to understand the environment where it’s installed and works with it in ways that offer advanced motion detection based recording and other progressive features.

The Perimeter Protection function works to drastically reduce unwanted motion events. Virtual tripwires are used to reduce the number of pixels that have to be triggered in very specific portions of the camera’s view. This feature is also able to distinguish people and vehicles from other moving objects that can cause unwanted motion recording.

This camera’s Face Detection function collects images of faces from digital images it captures or from another exterior source. The AI is able to analyze the images provided very quickly and help build a database if this camera is working with a recorder that has AI.

For a very long time, the longest your cables could be, when working with POE, was 328 feet or 100 meters. This camera uses the new ePOE technology to go much further as long as both the camera and the Poe switch have the ePOE technology. It can transmit a max bandwidth of 10 Mbps up to 2624 feet (800 meters). It can also transmit up to 100 Mbps up to 984 feet (300 meters).

The wide-angle 2.8 mm lens that this camera uses will allow you to detect objects at approximately 184 feet, observe objects at approximately 72 feet, recognize people at approximately 36 feet and identify people at approximately 20 feet.

Enhanced POE

ePoE you can simplify the wiring requirements enabling you to reach distances of a single run up to 800 meters (over 2,600 feet) at a speed of 10Mbps.

Features

Starlight

Starlight security cameras outperform and overachieve all traditional night vision cameras. Starlight technology is able to capture high-quality images in places with little to no light as well as areas with no light whatsoever. It is the latest technological development in nighttime and low-light surveillance.

ePOE

ePoE, or enhanced Power over Ethernet, is an innovative solution that utilizes specialized algorithms capable of extending how far both IP and analog security cameras can reach. ePoE devices are now standard on ONVIF devices and can even be incorporated into traditional PoE systems. What makes ePoE devices different is that they have the capability of converting coaxial infrastructures with the latest IP devices. This capability makes it possible to increase transmission distances through both coaxial and ethernet cables.

Weather Resistant

140°F | 60°C
Heat Rating

-22°F | -30°C
Cold Rating

IP67
Weather Rating


Remote Viewing Apps

The ability to view security camera systems remotely has transformed the video surveillance industry in powerful ways. Prior to this innovation, manned users were needed on location to view live feeds. Now, it’s possible to view live camera feeds digitally through network-connected devices. IP security cameras make this innovation possible. With remote viewing, anyone, from anywhere in the world, can visibly watch live camera feeds.

Camera
Features People Counting | Face Detection | 3D DNR | Perimeter Protection | Starlight™ | WDR | ePoE
Lens 2.8mm Fixed Lens
Megapixel 5MP
Image Resolutions (2592 × 1944) / 2688 × 1520 / 2560 × 1440 / 2304 × 1296 / 1080P (1920 × 1080) / 1.3M (1280 × 960) / 720P (1280 × 720) / D1 (704 × 576/704 × 480) / VGA (640 × 480) / CIF (352 × 288 / 352 × 240)
Sensor Size 1/2.7” Progressive Scan CMOS
IR Distance 164 FT
Weather Protection IP67
Impact Protection IK10
Voltage DC 12V (±30%), PoE (802.3af) (Class 0)
Temp Range (-22° F to +140° F)/Less than 95% RH
Dimensions 4.80” × 3.50”
Weight 1.01 lb
Audio Capable With External Mic
SD Card Compatible Yes
Downloads
IPVD-ELS5IR28A-AI-EP Document Downloads
Product Specifications Detailed Feature List and Product Specifications
