Elite 16CH 1U 4K H.265+ PENDVR

(1 customer review)


Out of stock


Join the waitlist to be emailed when this product becomes available

SKU: PENDVR-EL16ME4K-AI Categories: ,


Number of Cameras
Number Of HDD
Max Recorder Resolution

Introducing our newest 4k Capable DVR, the PENDVR-EL16ME4K-AI. This unit features the powerful new 4KN encoding features. This allows the unit to encode 4k input at nearly full 4k but at a much higher frame rate of 15 FPS for far smoother in-motion detail than standard 4k!

Not only can it accept COAX cameras all the way up to 8MP, but also known as 4k, but it has an additional 16 IP camera channels maxing out at a whopping 32 channels of CCTV recording power.

Featuring SMD Plus, Smart Motion Detection, on all 16 COAX channels, this unit can use AI power to discern human and vehicle targets for better alerting than ever.

For other AI-enhanced features, the PENDVR-EL16ME4K-AI can perform facial capture and recognition on up to two channels. It can then compare this to up to 10 databases with a max of 20,000 face images in total.

Additionally, the system is able to perform perimeter protection on two channels. This allows the user to draw tripwire and intrusion boxes for smart alerting and recording based on these trigger rules.

With a limited number of AI channels available at once, it used to be tedious to swap smart plans and manually elect options. Now with Scheduled AI, you can pre-program when and which AI features your camera channels are using.

Never miss an important moment with h265-powered AI encoding., This machine can compress even more data than h264, 60% more at 4k in fact, without loss, for more footage at the cost of less hard disk space!

With customizable alarm audio, you can now upload your own audio files to the system, allowing alarm alerts to playback a familiar tone you recognize.

This product comes with a 3 year warranty! FREE US based tech support for the life of the product! Don't forget to download our FREE remote viewing applications, available on IOS & Android! For further warranty information, click here.

Ultra HD Resolution

Take your security to the next level and experience incredible detail with 4K Ultra-High resolutions.


4K Ultra High Definition Resolution

4K resolution is a resolution that consists of 4,000 pixels. 4K, which is specifically 3840 × 2160 (4K UHD), has now become the standard for video quality. 4K resolution is not just for TV graphics. It’s now being utilized for modern video surveillance systems and can be an important aspect for high-quality security cameras in order to provide a better quality recording, deliver better results for analysis, and ultimately make it clearer to see for everything from security to entertainment.

Remote Viewing Apps

The ability to view security camera systems remotely has transformed the video surveillance industry in powerful ways. Prior to this innovation, manned users were needed on location to view live feeds. Now, it’s possible to view live camera feeds digitally through network-connected devices. IP security cameras make this innovation possible. With remote viewing, anyone, from anywhere in the world, can visibly watch live camera feeds.

Number Of Cameras 16 BNC + 16 IP or 32 IPC's (up to 8MP)
Number Of SATA Connections 1
Has Alarm Inputs / Outputs Yes
Video Output Types 1 HDMI & 1 VGA
Video Output Resolutions: HDMI: 3840 × 2160 | 1920 × 1080 | 1280 × 1024 | 1280 × 720 | VGA: 1920 × 1080 | 1280 × 1024 | 1280 × 720
Size 1U
Resolutions Capable 4K | 6MP | 4K-N | 4 MP | 3 MP | 4M-N | 1080P | 720P | 960H | D1 | CIF
Max Bandwidth 128 Mbps
Display Screen Split When IP extension mode not enabled: 1/4/8/9/16 When IP extension mode enabled: 1/4/8/9/16/25/36
Compression of Video H.265+
Connection Apps Smart PSS, DMSS , Elite Viewer Pro
Document Downloads
Product Specifications Detailed Feature List and Product Specifications
Product Manual Original Product Manuals
