The Elite Series IPVD-ELSX2IR28A is a unique vandal dome camera that has two separate 2.8mm lenses that can be turned in various directions and can therefore easily take the place of multiple cameras. Using the H.265 video compression settings, this camera operates using less storage space and bandwidth (up to 70%) over previous H.264 compression codecs.
This camera was made so it could be used indoors and outdoors in various weather conditions. The IP67 rating confirms that this camera is perfect for a wide range of uses and provides a high level of protection from dust and water intrusion. With an IK10 impact rating, you can be confident when mounting your cameras lower that it will be able to withstand an approximate impact of 5kg dropped from approximately 15 inches. Additionally, the 4KV lightning rating protects the camera and housing against lightning damage.
Among the features included, True WDR (120dB) allows your video to be optimized so that bright and dark areas are balanced and your video is usable. With the STARVIS™ CMOS Starlight Technology, you’ll be able to use these cameras where you don’t have optimum lighting conditions. They are perfect for use where you have very little lighting but you will still be able to see clearer, color images for longer periods of time.
Thanks to the Intelligent Video System (IVS) technology, your camera can use the intelligent video analytics to sense and respond to various events. Tripwire Analytics, Abandoned and Missing Objects, Intrusion and even Face Detection are actions that you can set to trigger your DVR to record, send a notification, and activate a connected alarm.
This camera includes a 2 year warranty, US based tech support and remote viewing software.
|Features||Starlight™, True WDR, IK10 Vandal Rating, IVS|
|Image Resolutions||1080P(1920x1080)/1.3M(1280x960)/ 720P(1280×720)/D1(704×576/704×480)/ VGA(640×480)/CIF(352×288/352×240)|
|Sensor Size||Two 1/2.8 inch 2MP progressive scan CMOS|
|IR Distance||66 feet|
|Voltage||DC12V, PoE (802.3af)(Class 0)|
|Temp Range||-22°F to +140°F / Less than 95% RH|
|Dimensions||4.79in x 4.79in x 2.57in|
IPVD-ELSX2IR28A Document Downloads
|Product Specifications||Detailed Feature List and Product Specifications|
Elite Series DVR / NVR / IP Camera Remote Viewing Downloads
|Smart PSS-v1.0 - PC Surveillance Downloads: Software & Manual||Windows XP / Vista / Windows 7,8,10 / Windows Server 2003 & 2008|
|Smart PSS-v2.01 Downloads: Software & Manual||Windows XP / Vista / Windows 7,8,10 / Windows Server 2003 & 2008|
|PSS - PC Surveillance Downloads: Software & Manual||Windows XP / Vista / Windows 7,8,10 / Windows Server 2003 & 2008|
|Elite Series Smart Player Downloads: Software & Manual||Windows XP / Vista / Windows 7,8,10 / Windows Server 2003 & 2008|
|Smart PSS MAC Surveillance Downloads: Software & Manual||SMART PSS FOR MAC (All MACs)|
|Smart PSS-V2 - MAC Surveillance Downloads: Software & Manual||SMART V2 PSS FOR MAC (All MACs)|
|Smart PSS BETA Downloads: Software & Manual||SMART BETA PSS FOR MAC (All MACs)
This software is currently in Beta please report any bugs that you encounter, the GM version of this app will soon be available. Thank you for your patience
|Smart Player Elite Mac Downloads: Software & Manual||Download|
|PSS MAC Surveillance Downloads: Software & Manual||MacOSX (All Mac Versions)|
|PSS MAC Surveillance Downloads: Software & Manual||MacOSX 10.6.8 (Snow Leopard only)|
|Elite Mac Safari Plugin Downloads: Software||MacOS (All Mac Versions)|
|iPhone / iPad Mobile Viewing Software||iPhone / iPad App from the Apple App Store|
|Android Mobile Phone Viewing Software||Android Phone App from the Google Play Store|
|Android HD Tablet Viewing Software||Android Tablet App from the Google Play Store|
Elite Series DVR / NVR / IP Camera Tools & Utilities
|Configuration Tool Downloads: Software & Manual||Windows|
|Smart Player Downloads: Software & Manual||Windows|
|Video Converter Downloads: Software & Manual||Windows|
|HDD Download-Tool Downloads: Software & Manual||Windows|
|Configuration Tool Mac Downloads: Software & Manual||Mac|
|Safari Reset Tool Downloads: Software||MacOSX (All Mac Versions)|
|POS Instructions Downloads: Manual|
