Here is the latest addition to our Elite series . . . a 5MP HD-CVI Fisheye camera that offers a panoramic fisheye lens with a 1/2.8 inch progressive scan CMOS image sensor that is perfect for capturing events from a wide area and from different angles, which might eliminate the need to have multiple cameras covering the same area.
Now you can get a 360° view in 5MP up to 20fps or 4MP at up to 30fps with 120db of true WDR (wide dynamic range) and featuring Starlight technology, which enables the camera to retain a color image when you have minimal ambient lighting available. With 2D & 3D noise reduction, you’ll be able to get a cleaner image by eliminating noise while comparing two of the same frames. This feature also reduces bandwidth which can save space on your hard drive.
Our Elite 5MP Fisheye camera has more than 10 dewarping modes available on specific Elite Pentabrid DVRs which enables you to dewarp the image directly from the DVR instead of having to use the free computer software to dewarp. This camera comes with a built-in microphone that features broadcast quality audio over coaxial or siamese cable and is best paired with our Elite DVRs where no additional cable is required to run back to the DVR since the audio functions over the cable.
This camera has Smart IR technology that helps to ensure brightness in a black and white image under limited illumination that adjusts to the intensity of the LEDs to compensate for the distance of an object and to also prevent overexposure when an object moves closer to the camera. You don’t need any special power supplies for this camera as it works off of regular 12v DC power +/- 30% and uses up to 7.3 watts with the IR LEDs turned on.
We provide FREE technical support for the life of the product along with FREE remote viewing apps for Android and Apple devices.
|Features||Fisheye Lens, True WDR, IK10 Vandal Rating|
|Lens||1.4mm Panoramic Lens|
|Image Resolutions||5MP (2592 x 1944)|
|Sensor Size||1/2.8 inch CMOS|
|IR Distance||32.8 feet|
|Voltage||12V DC ±30%|
|Temp Range||-22°F to +140°F, Less than 95% RH|
|Dimensions||4.97in x 4.97in x 1.6in|
CVIVD-ELS5FA Document Downloads
|Product Specifications||Detailed Feature List and Product Specifications|
|Product Manual||Original Product Manuals|
Elite Series DVR / NVR / IP Camera Remote Viewing Downloads
|Smart PSS-v1.0 - PC Surveillance Downloads: Software & Manual||Windows XP / Vista / Windows 7,8,10 / Windows Server 2003 & 2008|
|Smart PSS-v2.01 Downloads: Software & Manual||Windows XP / Vista / Windows 7,8,10 / Windows Server 2003 & 2008|
|PSS - PC Surveillance Downloads: Software & Manual||Windows XP / Vista / Windows 7,8,10 / Windows Server 2003 & 2008|
|Elite Series Smart Player Downloads: Software & Manual||Windows XP / Vista / Windows 7,8,10 / Windows Server 2003 & 2008|
|Smart PSS MAC Surveillance Downloads: Software & Manual||SMART PSS FOR MAC (All MACs)|
|Smart PSS-V2 - MAC Surveillance Downloads: Software & Manual||SMART V2 PSS FOR MAC (All MACs)|
|Smart PSS BETA Downloads: Software & Manual||SMART BETA PSS FOR MAC (All MACs) This software is currently in Beta please report any bugs that you encounter, the GM version of this app will soon be available. Thank you for your patience|
|Smart Player Elite Mac Downloads: Software & Manual||Download|
|PSS MAC Surveillance Downloads: Software & Manual||MacOSX (All Mac Versions)|
|PSS MAC Surveillance Downloads: Software & Manual||MacOSX 10.6.8 (Snow Leopard only)|
|Elite Mac Safari Plugin Downloads: Software||MacOS (All Mac Versions)|
|iPhone / iPad Mobile Viewing Software||iPhone / iPad App from the Apple App Store|
|Android Mobile Phone Viewing Software||Android Phone App from the Google Play Store|
|Android HD Tablet Viewing Software||Android Tablet App from the Google Play Store|
Elite Series DVR / NVR / IP Camera Tools & Utilities
|Configuration Tool for VDB-EL1VAW-B: Software & Manual||Windows|
|Configuration Tool Downloads: Software & Manual||Windows|
|Smart Player Downloads: Software & Manual||Windows|
|Video Converter Downloads: Software & Manual||Windows|
|HDD Download-Tool Downloads: Software & Manual||Windows|
|Configuration Tool Mac Downloads: Software & Manual||Mac|
|Safari Reset Tool Downloads: Software||MacOSX (All Mac Versions)|
|POS Instructions Downloads: Manual|
