4 Channel Mini 1U Eco Series H.265+ DVR W/ SMD+

(1 customer review)

Original price was: $79.46.Current price is: $71.51.

Save 10%

In stock

Hard Drive – Optional

Recommended Accessories

18x18x5 Small Steel Lockbox with fan designed for 1U DVRs & NVRs
18x18x5 Small Steel Lockbox with fan designed for 1U DVRs & NVRs
21x24x8 Large Steel Lockbox with fan designed for 1.5 and 2U DVRs & NVRs
21x24x8 Large Steel Lockbox with fan designed for 1.5 and 2U DVRs & NVRs


Number of Cameras
Number Of HDD
Max Recorder Resolution

For smaller installations utilizing COAX connections, take a look at our new 1080p Hybrid DVR capable of accepting up to 5MP cameras, this is the PENDVR-ELE4ME-AIV2. This recorder comes with a single HDD bay, perfect for its size and number of channels

This recorder is great for customers who only need a smaller system and are fine with 1080p resolution. Often this is the case on previously existing 1080p installations.

On a single channel, the PENDVR-ELE4ME-AIV2 can perform AI features, and you can choose whichever AI feature you’d like to use.

The PENDVR-ELE4ME-AIV2 can utilize its AI channel for either Smart Motion Detection+ (SMD+), IVS perimeter protection or it can also use Facial Recognition. This allows it to compare captured face metadata to one of the face images in up to 10,000 pictures across a max of 10 total individual databases. The attributes it can compare are gender, age, expression, glasses, mustache, and face mask.

Using BNC, also known as COAX connections, this recorder has 4 inputs. While its native resolution is 1080p, it can actually accept COAX cameras up to 5MP and utilize a resolution called 5M-N. This allows the cameras to record at full vertical 5MP resolution, but slightly reduced horizontal resolution for very little loss in image quality compared to full 5MP, but still greater than 1080p.

The PENDVR-ELE4ME-AIV2 can accept an additional additional 2 IP cameras for a total of 6 cameras.

The Recorder supports the newest in AI-aided h265 video compression encoding. This means a more than 60% gain at recording high resolutions over its older h264 counterpart. More footage, better picture, no compromises!

This product comes with a 3 year warranty! FREE US based tech support for the life of the product! Don't forget to download our FREE remote viewing applications, available on IOS & Android! For further warranty information, click here.

Free Remote Viewing Capability

All of our DVR's & NVR's have remote viewing capabilities. Free Apps & Software are for PC, Mac, iPhone, iPad, Android and Tablets


High Definition Resolution

High Definition resolution is not just for TV graphics. It’s now being utilized for modern video surveillance systems and can be an important aspect for high-quality security cameras in order to provide a better quality recording, deliver better results for analysis, and ultimately make it clearer to see for everything from security to entertainment.

Remote Viewing Apps

The ability to view security camera systems remotely has transformed the video surveillance industry in powerful ways. Prior to this innovation, manned users were needed on location to view live feeds. Now, it’s possible to view live camera feeds digitally through network-connected devices. IP security cameras make this innovation possible. With remote viewing, anyone, from anywhere in the world, can visibly watch live camera feeds.

Number Of Cameras 4
Number Of SATA Connections 1
Has Alarm Inputs / Outputs No
Video Output Types HDMI/VGA
Video Output Resolutions: 1920 × 1080; 1280 × 1024; 1280 × 720
Size Mini 1U
Resolutions Capable 5M-N; 4M-N; 1080P; 1080N; 720P; 960H; D1; CIF
Max Bandwidth 32 Mbps
Display Screen Split When IP extension mode not enabled: 1/4 When IP extension mode enabled: 1/4/6
Compression of Video H.265+
Connection Apps Elite Viewer Pro, DMSS, Smart PSS
Perimeter Protection Yes
Object Detection No
Face Detection No
Face Recognition Yes
Smart Motion Detection Yes
Document Downloads
Product Specifications Detailed Feature List and Product Specifications
Product Manual Original Product Manuals
