8CH AI Series H.265+ DVR

(1 customer review)


In stock

Hard Drive – Optional

Recommended Accessories

18x18x5 Small Steel Lockbox with fan designed for 1U DVRs & NVRs
18x18x5 Small Steel Lockbox with fan designed for 1U DVRs & NVRs
21x24x8 Large Steel Lockbox with fan designed for 1.5 and 2U DVRs & NVRs
21x24x8 Large Steel Lockbox with fan designed for 1.5 and 2U DVRs & NVRs


Number of Cameras
Number Of HDD
Max Recorder Resolution

We have a brand new 1080p Hybrid DVR capable of accepting up to 5MP cameras, this is the PENDVR-ELE8ME-AI3. This is a 1U 1 hard drive bay unit so make sure to max that out to 10TB!

This recorder is great for customers with existing 1080p installations looking to upgrade some of their equipment while utilizing most of their existing hardware, maybe begin transitioning to IP cameras, and expand into the future too. It is also equipped with AI features such as real-time facial recognition, smart motion detection (SMD+), and IVS based perimeter protection.

For COAX connections, this recorder has 8 inputs. While its native resolution is 1080p, it can actually accept COAX cameras up to 5MP, and utilize a resolution called 5M-N. This allows the cameras to record at full vertical 5MP resolution, but slightly reduced horizontal resolution for very little loss in image quality compared to full 5MP, but still greater than 1080p.

This recorder can accept an additional 4 IP cameras on top of its 8 coaxial connections. These IP cameras can be up to 6 MP. If you end up expanding into all IP, all 8 coaxial channels can be converted to IP for a total of up to 12 IP cameras.

This recorder can do AI features for a single channel, and you can choose whichever AI feature you’d like to use.

The PENDVR-ELE8ME-AI3 can utilize its AI channel for comparing captured face metadata to one of the face images in up to 10,000 pictures across a max of 10 total individual databases. The attributes it can compare are gender, age, expression, glasses, mustache, and face mask.

With SMD+ and AI aided IVS perimeter protection, you’ll be able to either set motion detection rules or tripwire/intrusion box rules which ignore targets that are not people or vehicles, greatly eliminating false alerts!

The Recorder supports the newest in AI-aided h265 video compression encoding. This means a more than 60% gain at recording high resolutions over its older h264 counterpart. More footage, better picture, no compromises!

This product comes with a 3 year warranty! FREE US based tech support for the life of the product! Don't forget to download our FREE remote viewing applications, available on IOS & Android! For further warranty information, click here.

Free Remote Viewing Capability

All of our DVR's & NVR's have remote viewing capabilities. Free Apps & Software are for PC, Mac, iPhone, iPad, Android and Tablets


High Definition Resolution

High Definition resolution is not just for TV graphics. It’s now being utilized for modern video surveillance systems and can be an important aspect for high-quality security cameras in order to provide a better quality recording, deliver better results for analysis, and ultimately make it clearer to see for everything from security to entertainment.

Remote Viewing Apps

The ability to view security camera systems remotely has transformed the video surveillance industry in powerful ways. Prior to this innovation, manned users were needed on location to view live feeds. Now, it’s possible to view live camera feeds digitally through network-connected devices. IP security cameras make this innovation possible. With remote viewing, anyone, from anywhere in the world, can visibly watch live camera feeds.

Number Of Cameras 8
Number Of SATA Connections 1
Has Alarm Inputs / Outputs No
Video Output Types 1 HDMI & 1 VGA
Video Output Resolutions: 1080P
Size Mini 1U
Resolutions Capable 5M-N; 4M-N; 1080p; 1080N; 720p; 960H; D1; CIF
Max Bandwidth 64 Mbps
Display Screen Split When IP extension mode not enabled: 1/4/8/9 | When IP extension mode enabled: 1/4/8/9/16
Compression of Video H.265+
Connection Apps Smart PSS 2.0+, Elite Viewer Pro
Perimeter Protection Yes
Object Detection No
Face Detection Yes
Face Recognition Yes
Smart Motion Detection Yes
Document Downloads
Product Specifications Detailed Feature List and Product Specifications
Product Manual Original Product Manuals
